Single board computer ( single board pc)

For a cloud-based system, for managing zigbee sensors

Electronic fuse and switching circuit, replacing traditional fuses, and additionally remotely controllable

Each sensor is connected to the sensor control module separately. You only need to buy the sensors for the module that are needed on the given ship. We can measure collisions with the accelerometer, tilt with the gyroscope, and the system can send an alarm in case of extreme values. If necessary, automations can be connected to the light sensor ( e.g. anchor light, navigation light switching). A rain sensor can be based on moisture measurement or operated with a rain quantity counter. Automations can be connected to it.

The position data is always stored in the az- smart tracking cloud system. The position and speed of the ship can be continuously monitored. Uploading the position data can be time-based ( e.g. 10, 20, 30, 60 sec) or distance-based ( e.g. 1 , 2.5, etc. meters) . average speed, maximum speed, and can be saved in KML (Google Earth ) format, on the basis of which a map of the traveled route can be created with the Google Earth program.
